3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption

  • 3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption
  • 3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption
  • 3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption
Place of Origin CHINA
Brand Name JIETAI ZHINENG
Certification CE, ISO9001
Model Number 6SXM-192A
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details WOODEN CASE
Delivery Time 10-15 work days
Payment Terms L/C, T/T
Supply Ability 100Pcs/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Rice Sorting Capacity(T/H) 2.0-4.0
Power 220V/50HZ Color Blue-White
Condition New Sorting Accuracy(%) ≥99.99
Dimension(l*w*h) 1687*1515*1910mm Function Color Sorter,sorting Different Color Materials
After-sales Service Provided Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service,Online Support,Field Installation,commissioning And Training Certification ISO9001,CE
Name Rice Color Sorter Machine
High Light

192 Channels Rice Color Sorter Machine

,

Rice Color Sorter Machine Low Consumption

,

3 Chutes Rice Colour Sorter
Leave a Message
Product Description

RGB CCD 3 Chutes 192 Channels Orange Rice Color Sorter Machine Low Consumption



Anhui Jietai Intelligent Technology Co., Ltd. is an industry-leading R&D and manufacturer of intelligent color sorters. We specially developed a cost-effective sorting and processing equipment for rice mill factories, farms and cooperatives,this product integrates ultra-clear camera system, targeted positioning system, magnetic ejectors and other core technologies and components.When sorting rice,accuracy adjusting freely,low consumption and high capacity. At the same time with the platform-integrated design and intelligent production,the stability and reliability of products are significantly ahead.Installation and maintenance are convenient,easy to operate, bringing a better experience to our customers.



Technical Parameters

Model
NO.

 6SXM-192A

Accuracy
(Percent)

 99.99

Optical Carryover
(Bad:Good)

 30:1

Capacity
(T/H)

 2.0-4.0

Power
(kwh)

 2.2

Air Pressure
(Mpa)

 0.6-0.8

Air Consumption
(L/M)

≤1.2

Dimension(mm)
(L*W*H)

 1687*1515*1910

Weight
(kg)

 700



Product Features

►IOT color sorter system

Highly humanized interface of human-machine interaction, Smart cloud interconnect, Remote control, accurate big data statistics and analysis.Call the multiple preset color selection modes at any time.



►HD image capture system

Full-color high-speed CCD sensor recognizes 0.04mm²area,Nikon camera,super high resolution,ultra-sensitive ,wide vision, low distortion.



►Multi-core parallel image processing system

Multi-core parallel image processing system, flexible matching and synchronous operation of color sorting/shape sorting.



►Intelligent high-frequency solenoid valve

Ultra-low air consumption, ultra-low carryover ratio, intelligent detect the working status of ejectors,avoid the fault and prolong the life of ejectors.



►Shadowless colorful spectrum LED

Taiwan Yiguang,shadow-less LED colorful light source, multi-angle shadow-less light path technology.



►Input and Output system

Adopting a new pressure-resistant structure to feed, which greatly increases the output of the machine and ensures the stability of the machine.The straight-through discharge structure solves the problem of material blocking and stacking.

Application Fields

Jietai rice color sorter, as an intelligent machine, can detect and remove mildewy rice, white rice,broken rice, glass and stone in the raw material and classify rice based on the color,shape and other differences,Jietai rice color sorter always provides customers with intelligent,professional and comprehensive sorting solutions,such as sorting extremely light yellowrice, backline rice, needle tip, diseased rice and small broken rice.

3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 0





This model also can sort beans,grains and so on.

3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 1



JIETAI Color Sorter Core Parts
3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 2  * Touch Screen Interface:Independent-research operate interface.
3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 3                     * Camera:Nikon camera,super high resolution,Ultra-Sensitive ,wide vision, low distortion.

3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 4     * Chip:Multi-core parallel image processing system,

                                                    flexible matching and synchronous operation of color sorting/shape sorting.


3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 5* Filter:SMC from Japan.

3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 6           * Touch Screen System:Windows CE system.

3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 7 * Sensor:Toshiba from Japan,Full-color high-speed CCD sensor recognizes 0.04mm²accurately.


3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 8 * Ejectors:Italy core technology, new special high wear-resistant material.



3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 9 * LED:Taiwan Yiguang,shadow-less LED colorful light source,

                                                 multi-angle shadow-less light path technology.

Packaging&Shipping
Our products use professional wooden cases with PE plastic bag..Package size will depend on each model size.
3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 10
Our Service

Before sales services

We will help you know about our color sorter,meets your special requirement according to actual condition.If you want to have your own logo printed on the macine or want to customize your own color for the machine, tell us,we can help you.

After sales services

1. Provide free training,consulting and technical support for users;

2. Provide personalized programs to the demands of customers;

3. Upgrade software for free for a life time;

4. Provide free warranty service for one year(except the wearing spare parts);

5. Provide 7*24 hours consultation and urgent servicce for users.



Contact Us

3 Chutes 192 Channels Rice Color Sorter Machine Low Consumption 11


FAQ
1.Q:How about the guarantee period?
A:The color sorter(excluding the wearing parts) is warranted for one year for free from date of purchase.we provide a lifetime maintenance service.

2.Q:Will you accept L/C as payment?
A:L/C ,T/T is OK.

3.Q:How about engineers service oversea?
A:Engineers available to service machinery overseas.

4.Q:How to use the machine?
A:We will supply customer the installation catalog or video online.We will ask our engineer to teach you and Our engineers will also train your person when they go to your place for debugging.


5.Q:How about the sample machines for testing?
A:Sample sending for testing is welcomed.Or you send these three photos,the raw material,good material (which is you want) ,bad material (which is you want to discard).We send our sorting video to you.

6.Can you supply the accessories parts of color sorter?
A:Yes,we can supply some spare parts when you need.
